Tính năng
Greater efficiency and power handling
Dual JBL low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
JBL 2414H-C 25 mm (1 in) polymer diaphragm compression driver
Improves high frequency performance as well as system reliability
Advanced network topology crossover design
Shapes frequency response and delivers "coherent summation" in the crossover region
Extra bass without sacrificing performance
A "Quasi 3-Way" design offers the extra bass for which a dual fifteen system is designed, but without sacrificing performance in the critical mid-range. The upper woofer produces mid-frequencies and bass, while the lower woofer concentrates on bass only. The reduction in mid-range phase cancellation greatly improves midrange sound quality and coverage.
High-voltage capacitors and inductors
High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
Progressive Transition™ high frequency waveguide
Provides superior coverage control, reduced distortion, and smoother frequency response
Rugged, acoustically superior enclosure
The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
SonicGuard™ protection
SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
Durable design
Non-resonant, all-steel handles are used along with an attractive 18-gauge hexagon perforated steel grille to protect components from damage.
Thông số và Tải về
Mục#: JRX225
Mô tả sản phẩm
Affordable, reliable, high quality sound
thông tin chi tiết
Kích thước
Tính năng
Trong hộp gồm có
- 1 x JRX225
bản hướng dẫn & Tải về
Hướng dẫn sử dụng mới nhất, Hướng dẫn nhanh cùng các tài liệu khác.
